Closed-Die, Open-Die Forgings and Rolled Rings
A 718 valve-body forging, a rolled ring for a compressor: both come off the same line. The heat number is marked on the part.
| Grades | Inconel 718, X-750, 625, 600; Waspaloy; Rene 41; Nimonic 80A |
| Forms | Closed-die and open-die forgings, rolled rings, flange blanks |
| Size | Rings to 1,200 mm OD; forgings to 300 kg |
| Condition | Solution annealed and aged as specified |
| Standards | AMS 5662 / 5663 / 5667 / 5707; ASTM B637 |
| Testing | UT and PT on request; dimensional report; EN 10204 3.1 / 3.2 |
Applications
- Valve bodies and trim
- Compressor and turbine discs
- Flange and ring forgings
- High-temperature structural parts
Traceability
ISO 9001EN 10204 3.1EN 10204 3.2AMS 5662 / 5663ASTM B637NACE MR0175
